Products Description
WOYE Orchard Tractors are compact and medium-power tractor configurations designed for agricultural work between and around established tree rows.
Orchard operations often require a different tractor configuration from open-field work. Tree-row spacing, canopy clearance, ground conditions, turning space, traction, and implement requirements can all affect the suitable tractor dimensions and configuration.
WOYE provides orchard-compatible tractor configurations from compact models to higher-power options, allowing the tractor to be matched with the working environment and implements required for the operation.
Key Specifications
|
Specification |
WOYE Orchard-Compatible Configurations |
|
Power |
25–70 HP |
|
Drive |
4WD configurations available |
|
Wheelbase |
1,680–1,965 mm on selected models |
|
Ground Clearance |
310–330 mm on selected models |
|
Wheel Track |
Adjustable configurations available |
|
Transmission |
8F+2R, 8+8 and 8F+8R configurations |
|
PTO |
540/720, 540/1000 or model-specific configurations |
|
Three-Point Hitch |
Category I on selected models |
|
Hydraulic System |
1–2 hydraulic output groups on selected models |
|
Turning Radius |
Model-specific |
|
Operating Weight |
Approximately 980–1,660 kg on selected models |
Specifications vary by model and configuration. Final dimensions, tire selection, PTO speed, hydraulic configuration and implement compatibility should be confirmed according to the tractor and intended application.
Orchard Tractor Configurations
WOYE's orchard-compatible range covers several power classes. The suitable configuration depends on the available space between tree rows, terrain, required implements and the level of traction and lifting performance required.
The 25HP tractor is a compact 4WD configuration with a 1,680 mm wheelbase and 310 mm ground clearance.
Published specifications:
• Rated Power: 25 HP / 18.4 kW
• Drive: 4×4; 2WD optional
• Transmission: 8F+2R
• PTO: 540/720 rpm
• Wheelbase: 1,680 mm
• Ground Clearance: 310 mm
• Overall Dimensions: 2,900 × 1,200 × 1,400 mm
• Weight: 980 kg
• Hydraulic Output: 1 group, expandable to 2
The model is listed for orchard and other agricultural applications.
The 30HP tractor combines a compact chassis with an adjustable wheel-track range.
Published specifications:
• Rated Power: 30 HP
• Wheel Track: 1,000–1,200 mm
• Wheelbase: 1,745 mm
• Ground Clearance: 310 mm
• Weight: 1,310 kg
• Transmission: 8F+2R
• PTO: 540/1000 rpm
• Overall Dimensions: 3,350 × 1,400 × 2,000 mm
The model is listed for orchard and other confined agricultural environments.
The 35HP model has a dedicated orchard tractor configuration. Its compact layout is intended for narrow-row agricultural environments.
Published specifications include:
• Rated Power: 35 HP / 25.7 kW
• Engine: Changchai 4G33T / Quanchai 4C3-35V22
• Engine Type: Inline 4-cylinder, water-cooled, 4-stroke
• Drive: 4×2 / 4×4 configurations
• PTO: 540/720 rpm or 540/1000 rpm optional
• Turning Radius: 1.08 m
Additional performance claims published on the existing orchard page have not been included here because they require further verification.
The 40HP tractor provides a higher-power option within the compact tractor range.
Published specifications include:
• Rated Power: 40 HP / 29.4 kW
• Drive: 4WD
• Transmission: 8+8
• PTO: 540/1000 rpm
• Hydraulic Lifting Capacity: 840 kg
The model is listed for orchard and other agricultural applications.
The 50HP 4WD tractor provides a higher-power configuration for orchard operations and is listed for narrow orchard work.
Published specifications:
• Power: 50 HP / 36.8 kW
• Drive: 4WD
• Operating Weight: 1,550 kg
• Ground Clearance: 330 mm
• Wheelbase: 1,980 mm
• Overall Dimensions: 3,550 × 1,430 × 2,000 mm
• Engine: LAIDONG
• Emission: China V
• Three-Point Linkage: Category I
• Hydraulic Output: 1 or 2 groups
• PTO: 540/1000 rpm
• PTO Spline: 6
The final configuration should be confirmed according to the required tractor and implement specifications.
The 60HP 4WD tractor provides a higher-power option for orchard operations where additional implement capacity is required.
Published specifications:
• Power: 60 HP / 44.1 kW
• Engine Brands: Laidong / YTO / Weichai
• Drive: 4×4
• Transmission: 8F+2R; 8F+8R optional
• Weight: 1,600 kg
• Overall Dimensions: 3,350 × 1,430 × 2,000 mm
• Three-Point Hitch: Rear Category I
• Hydraulic Output: 2 groups
• PTO: 540/1000 rpm
• Tires: 6.5-16 / 11.2-24
• Optional Tires: 7.5-16 / 11.2-28 / paddy tires
The model is listed for narrow agricultural spaces including orchards.
The WY704 provides a higher-power configuration while retaining adjustable rear track and a relatively compact wheelbase.
Published specifications:
• Model: WY704
• Power Class: 70 HP
• Drive: 4×4
• Rated Traction: 16.2 kN
• PTO Max Power: 43.8 kW
• Overall Dimensions: 3,560 × 1,650 × 2,350 mm
• Wheelbase: 1,965 mm
• Front Track: 1,150 mm
• Rear Track: 1,200–1,360 mm
• Minimum Ground Clearance: 330 mm
• Minimum Turning Radius: 2.85 ± 0.20 m
• Minimum Operating Weight: 1,660 kg
• Transmission: 8F+8R Shuttle Shift
• Hydraulic Steering
• Three-Point Hitch: Type 1
• Maximum Lifting Force at 610 mm: ≥10 kN
• PTO: 540/760 rpm; 540/1000 rpm optional
The adjustable rear track and overall configuration can be considered for orchard operations where the available working space and implement requirements are compatible with the tractor.
Why Orchard Tractor Configuration Matters
An orchard tractor works within an established tree layout. The tractor therefore needs to be evaluated against the physical space available in the orchard rather than by horsepower alone.
Width and Wheel Track
The distance between tree rows determines the available travel corridor, but the usable space can also be affected by mature canopy growth, irrigation equipment, grass strips and the width of the implement.
For this reason, overall tractor width and wheel track should be considered together with the actual orchard layout.
Selected WOYE models provide adjustable wheel-track configurations. The 30HP model, for example, lists a wheel-track range of 1,000–1,200 mm, while the WY704 provides a rear track range of 1,200–1,360 mm.
Ground Clearance
Ground clearance affects how the tractor moves over uneven orchard floors and around ground-level obstacles.
Selected WOYE compact and medium-power models provide approximately 310–330 mm of minimum ground clearance. The 25HP and 30HP models list 310 mm, while the 50HP and WY704 list 330 mm.
Wheelbase and Turning Space
Turning space matters particularly at orchard headlands and row ends.
A shorter wheelbase can contribute to maneuverability, but the actual turning requirement depends on the tractor's steering system, wheel track, tires, braking configuration and available headland space.
The 35HP orchard configuration lists a 1.08 m turning radius, while the WY704 lists a minimum turning radius of 2.85 ± 0.20 m. These figures are model-specific and should not be generalized across the range.
Four-Wheel Drive and Traction
Orchard ground conditions can vary between cultivated soil, grass-covered areas, slopes and uneven terrain.
4WD configurations can provide additional traction where the operating conditions require it. WOYE offers 4WD configurations across its compact and medium-power tractor range, with the exact drive configuration depending on the model.
PTO, Hydraulics and Three-Point Hitch
Orchard work often involves PTO-driven or tractor-mounted implements. The tractor therefore needs to be matched to the implement's power, PTO speed, hydraulic requirements, hitch category, weight and working width.
WOYE orchard-compatible configurations include:
- 540/720 rpm PTO
- 540/1000 rpm PTO
- Category I three-point hitch on selected models
- One or two hydraulic output groups depending on model
- Model-specific lifting capacity
For example, the 50HP model lists Category I three-point linkage, one or two hydraulic output groups and 540/1000 rpm PTO, while the WY704 lists a Type 1 three-point hitch and ≥10 kN maximum lifting force at 610 mm.
Orchard Applications
Depending on tractor and implement configuration, orchard tractors can be used for:
- Orchard-floor mowing
- Cultivation and soil work
- Spraying
- Fertilization
- Vegetation management
- Transportation and towing
- Other PTO-driven or three-point-mounted operations
Implement suitability depends on the implement specifications and the tractor configuration.
Matching the Tractor to Your Orchard
Before selecting an orchard tractor, compare the tractor with the actual operating environment:
- Distance between tree rows
- Mature canopy clearance
- Required tractor width
- Required wheel track
- Orchard headland and turning space
- Ground conditions and terrain
- Required ground clearance
- PTO requirements
- Hydraulic requirements
- Three-point hitch requirements
- Implement width and weight
The appropriate tractor configuration should be determined from these operating requirements together with the required implement specifications, rather than from horsepower alone.
Orchard Tractor Configuration Support
WOYE provides different tractor configurations for orchard operations, from compact 25–40HP models to higher-power 50–70HP options.
When requesting a quotation, provide the approximate row spacing, terrain conditions, main orchard operations and the implements to be used. WOYE can then evaluate the tractor dimensions, drive system, PTO, hydraulic system and other specifications against the intended application.
